Stainless Steel 304L Washers Manufacturer and Supplier
ASTM A194 / A193 Stainless Steel 304L Washer, SS 304L Washer, Steel UNS S30403 Washer, Stainless Steel Werkstoff Nr. 1.4307 Washer Dealers & Exporters
Leading Stainless Steel 304L Washer Stockist, SS 304L Washer Supplier, 304L Steel Washers Manufacture in India
Mahabali Steel Centre is India’s most prominent and well-reputed manufacturer and suppliers of high-quality Stainless Steel 304L Washer, serving varied industries to meet all needs of our clients. We are dedicated to manufacturing 304L Stainless Steel Washer especially the ASTM A193 SS 304L Washer, which is known for their high workability and corrosion resistance.
We offer customized and ready for sale SS 304L Fender Washer ranging from M10 to M100 to our clients in a number of industries and sectors. Stainless Steel 304L Lock Washer is used where locking action is required against rotation of the screw. SS 304L Flat Washer and Stainless Steel 304L Star Washer are supplied to industries for electrical and other engineering applications because of their high-quality finish and close tolerance. We offer Stainless Steel 304L Tab Washer of A2, A4, 200 Series grades, which are manufactured by cold forming to our clients all across the globe.
Our clients from a wide range of industries require Stainless Steel 304L Conical Washer DIN-6319 in the non-corrosive material which distributes the load under the bolt or nut evenly. Our SS 304L Dock Washer and Stainless Steel 304L Neoprene Washers are corrosion-resistant perform well in a wide range of temperatures, including cryogenic temperatures. We manufacture SS 304L Finishing Washers that meets our client’s requirements and specifications and that are in compliance with national and international standards.
Our manufacturing and fabrication process of Stainless Steel 304L Square Washers happens under the strict supervision of a professional workforce which ensures high quality and durability of all our products. Our Countersunk Washers are designed as an alternative to preparing a flat surface for use with countersunk screws, mainly for aesthetic purposes in gardening equipment, shafts, valves, hardware applications etc.
We are an SS 304L Washers manufacturer that keeps up the strict benchmarks for quality and are committed to constantly improving our offerings. We have acquired the name of being the manufacturer of SS washers because of present our clients with phenomenal quality, value, and service. We strive to be one of the largest stainless steel washer manufacturers.
Stainless Steel Din 1.4307 Wave Washers, Stainless Steel UNS S30403 Metal Washers, Stainless Steel Werkstoff Nr 1.4307 Star Washers, Steel 304L Flat Washer, Stainless Steel 304L Machine Washer, ASTM A193 Belleville Washers Wholesaler & Trader
Stainless Steel 304L Washers Specifications |
|
| Specifications | IS, BS, ASTM |
| Standard | ASTM / ASME - A/ SA 193 |
| Length | 3 mm to 200 mm |
| Size | M02 to M33 |
| Type | Flat Washers, Finishing Washers, Tab Washers, Conical Washers, Special Washers, Belleville Washer, Bonded Sealing Washer, Countersunk Finishing Washer, Dock Washer, Fender Washer, Lock Washer, Neoprene Washer, Square Bevel Washer, Star Washer |
Stainless Steel 304L Washers Equivalent Grades
| AISI Grade Equivalent | STANDARD | WERKSTOFF NR. | UNS | JIS | EN |
| AISI 304L | SS 304L | 1.4307 | S30403 | SUS 304L | X2CrNi18-9 |
Stainless Steel 304L Washers Sizes |
||||
| Sizes | A | B | C | Weight (lbs.) Per 100 Pieces |
| Inside Diameter | Outside Diameter | Thickness | ||
| 1/2 | 9/16 | 13/8 | 0.109 | 4 |
| 5/8 | 11/16 | 13/4 | 0.134 | 8 |
| 3/4 | 13/16 | 2 | 0.148 | 11 |
| 7/8 | 15/16 | 21/4 | 0.165 | 15 |
| 1 | 11/16 | 21/2 | 0.165 | 19 |
| 11/8 | 11/4 | 23/4 | 0.165 | 22 |
| 11/4 | 13/8 | 3 | 0.165 | 26 |
| 13/8 | 11/2 | 31/4 | 0.180 | 33 |
| 11/2 | 15/8 | 31/2 | 0.180 | 38 |
| 15/8 | 13/4 | 33/4 | 0.180 | 43 |
| 13/4 | 17/8 | 4 | 0.180 | 50 |
| 17/8 | 2 | 41/4 | 0.180 | 57 |
| 2 | 21/8 | 41/2 | 0.180 | 63 |
| 21/4 | 23/8 | 43/4 | 0.220 | 83 |
| 21/2 | 25/8 | 5 | 0.238 | 96 |
| 23/4 | 27/8 | 51/4 | 0.259 | 110 |
| 3 | 31/8 | 51/2 | 0.284 | 130 |
SS UNS S30403 Washers Chemical Composition
| Element | SS 304L |
| Ni | 8.0 – 12.0 |
| C | 0.030 |
| Mn | 2.0 max |
| P | 0.045 max |
| S | 0.030 max |
| Si | 1.0 max |
| Cr | 18.0 – 20.0 |
| Mo | - |
| N | - |
304L Stainless Steel Washers Mechanical Properties
| Element | SS 304L |
| Tensile Strength (MPa) min | 485 |
| Yield Strength 0.2% Proof (MPa) min | 170 |
| Elongation (% in 50mm) min | 40 |
| Rockwell B (HR B) max Hardness | 92 |
| Brinell (HB) max Hardness | 201 |
304L Stainless Steel Washers Physical Properties
| Element | SS 304 |
| Density(kg/m3) | 8000 |
| Elastic Modulus (GPa) | 193 |
| Mean Coefficient of Thermal Expansion (m/m/°C) | 17.2 / 17.8 / 18.4 |
| Thermal Conductivity (W/m.K) | 16.2 / 21.5 |
| Specific Heat 0-100°C (J/kg.K) | 500 |
| Electrical Resistivity(n.m) | 720 |
Latest Stainless Steel 304L Washers price list:
We Mahabali Steel Center offer best in class Stainless Steel 304L Washers at best market prices in India. Request the Latest Stainless Steel 304L Washers price list using the contact form here.
Stainless Steel 304L Washers Available Types |
|||
| SS 304L Flat Washers | 304L SS Finishing Washers | Steel 304L Tab Washers | 304L Steel Conical Washers |
| SS 304L Special Washers | 304L SS Belleville Washers | Steel 304L Bonded Sealing Washers | 304L Steel Countersunk Finishing Washers |
| SS 304L Dock Washers | 304L SS Fender Washers | Steel 304L Lock Washers | 304L Steel Neoprene Washers |
| SS 304L Square Bevel Washers | 304L SS Star Washers | Steel 304L Spring Washers | 304L Steel Plain Washers |
| SS 304L Metal Washers | 304L SS Wave Washers | Steel 304L Crank Washers | 304L Steel Square Washers |
| SS 304L Hex Washers | 304L SS Star Lock Washers | Steel 304L Aluminium Washers | 304L Steel Thrust Washers |
| SS 304L Serrated Washers | 304L SS Cup Washers | ||
Stainless Steel 304L Washers Available Standards |
|||
| ASTM | ASTM F436 Stainless Steel 304L Washers | ASTM F436M Stainless Steel 304L Washers | ASTM 1985 Stainless Steel 304L Washers |
| DIN | DIN 125 A (ISO 7089) Washers | DIN 125 B (ISO 7090) Washers | DIN 126 Washers |
| DIN 9021 Washers | DIN 440 R Washers | DIN 7349 Washers | |
| DIN 433 Washers | DIN 127 Washers | DIN 128 Washers | |
| DIN 434 Washers | DIN 435 Washers | DIN 1440 Washers | |
| DIN 440v Washers | DIN 6903 Washers | DIN 6916 Washers | |
| DIN 7349 Washers | DIN 7989 Washers | ||
| BS | BS 4320 Form A Washers | BS 4320 Form B Washers | BS 4320 Form C Washers |
| BS 4320 Form D Washers | BS 4395 Washers | ||
| IS / AS | IS 2016 Washers | AS NZS 1252 Washers | |
| JIS | JIS B 1186 Washers | JIS B 1256 Washers | |
| NF | NF E25-513 Z,M Washers | NF E25-513 L,LL Washers | |
