Stainless Steel 410 Washers Manufacturer and Supplier
ASTM A194 / A193 Stainless Steel 410 Washer, SS 410 Washer, Steel UNS S41000 Washer, Stainless Steel Werkstoff Nr. 1.4006 Washer Dealers & Exporters
Trusted Stainless Steel 410 Washer Stockist, SS 410 Washer Supplier, 410 Steel Washers Manufacture in India
Mahabali Steel Centre is a renowned enterprise that is engaged in offering a variety of Stainless Steel 410 Washer at best prices in India and across worldwide clients. We are one of the largest producers of 410 Stainless Steel Washer including ASTM A193 SS 410 Washer in India.
The increased chromium content in SS 410 Fender Washer and SS 410 Flat Washer increases their resistance to corrosion and their non-magnetic characteristic which finds applications in a variety of industries. We pride ourselves on our design and fabrication process of Stainless Steel 410 Tab Washer and Stainless Steel 410 Star Washer that meets the needs and specifications of our clients. We also supply Stainless Steel 410 Lock Washer to various sectors such as aerospace, metal processing, and mining, chemical as well as food processing units all over the globe.
We manufacture Stainless Steel 410 Conical Washer, Stainless Steel 410 Countersunk Washer and Stainless Steel 410 Neoprene Washers under the strict supervision of our professional team which guarantees the highest quality. Our clients use SS 410 Dock Washer when a flat surface is needed, during rehabilitation, railings etc. The dimensional accuracy of our products like Stainless Steel 410 Square Washers and SS 410 Finishing Washers are highly appreciated by our clients which makes it easy to install and maintain over long periods of time.
Being the leading S.S. 410 washer manufacturer, we offer products for optimum performance and robust usage. We are the manufacturer of SS 410 Washers that provide materials which are in strict compliance with the national and international standards. Contact us for the best stainless steel washer manufacturers in India and help us serve you better.
Stainless Steel Din 1.4006 Wave Washers, Stainless Steel UNS S41000 Metal Washers, Stainless Steel Werkstoff Nr 1.4006 Star Washers, Steel 410 Flat Washer, Stainless Steel 410 Machine Washer, ASTM A193 Belleville Washers Wholesaler & Trader
Stainless Steel 410 Washers Specifications |
|
| Specifications | IS, BS, ASTM |
| Standard | ASTM / ASME - A/ SA 193 |
| Length | 3 mm to 200 mm |
| Size | M02 to M33 |
| Type | Flat Washers, Finishing Washers, Tab Washers, Conical Washers, Special Washers, Belleville Washer, Bonded Sealing Washer, Countersunk Finishing Washer, Dock Washer, Fender Washer, Lock Washer, Neoprene Washer, Square Bevel Washer, Star Washer |
Stainless Steel 410 Washers Equivalent Grades
| AISI Grade Equivalent | STANDARD | WERKSTOFF NR. | UNS | JIS | EN |
| AISI 410 | SS 410 | 1.4006 | S41000 | SUS 410 | X12Cr13 |
Stainless Steel 410 Washers Sizes |
||||
| Sizes | A | B | C | Weight (lbs.) Per 100 Pieces |
| Inside Diameter | Outside Diameter | Thickness | ||
| 1/2 | 9/16 | 13/8 | 0.109 | 4 |
| 5/8 | 11/16 | 13/4 | 0.134 | 8 |
| 3/4 | 13/16 | 2 | 0.148 | 11 |
| 7/8 | 15/16 | 21/4 | 0.165 | 15 |
| 1 | 11/16 | 21/2 | 0.165 | 19 |
| 11/8 | 11/4 | 23/4 | 0.165 | 22 |
| 11/4 | 13/8 | 3 | 0.165 | 26 |
| 13/8 | 11/2 | 31/4 | 0.180 | 33 |
| 11/2 | 15/8 | 31/2 | 0.180 | 38 |
| 15/8 | 13/4 | 33/4 | 0.180 | 43 |
| 13/4 | 17/8 | 4 | 0.180 | 50 |
| 17/8 | 2 | 41/4 | 0.180 | 57 |
| 2 | 21/8 | 41/2 | 0.180 | 63 |
| 21/4 | 23/8 | 43/4 | 0.220 | 83 |
| 21/2 | 25/8 | 5 | 0.238 | 96 |
| 23/4 | 27/8 | 51/4 | 0.259 | 110 |
| 3 | 31/8 | 51/2 | 0.284 | 130 |
SS UNS S41000 Washers Chemical Composition
| Element | SS 410 |
| Ni | 0.75 |
| C | 0.15 |
| Mn | 1.00 max |
| P | 0.04 max |
| S | 0.03 max |
| Si | 1.00 max |
| Cr | 11.5 – 13.5 |
| Mo | - |
| N | - |
410 Stainless Steel Washers Mechanical Properties
| Element | SS 410 |
| Tensile Strength (MPa) min | 480 |
| Yield Strength 0.2% Proof (MPa) min | 275 |
| Elongation (% in 50mm) min | 16 |
| Rockwell B (HR B) max Hardness | - |
| Brinell (HB) max Hardness | - |
410 Stainless Steel Washers Physical Properties
| Element | SS 410 |
| Density(kg/m3) | 7800 |
| Elastic Modulus (GPa) | 200 |
| Mean Coefficient of Thermal Expansion (m/m/°C) | 9.9 / 11 / 11.5 |
| Thermal Conductivity (W/m.K) | 24.9 / 28.7 |
| Specific Heat 0-100°C (J/kg.K) | 460 |
| Electrical Resistivity(n.m) | 570 |
Latest Stainless Steel 410 Washers price list:
We Mahabali Steel Center offer best in class Stainless Steel 410 Washers at best market prices in India. Request the Latest Stainless Steel 410 Washers price list using the contact form here.
Stainless Steel 410 Washers Available Types |
|||
| SS 410 Flat Washers | 410 SS Finishing Washers | Steel 410 Tab Washers | 410 Steel Conical Washers |
| SS 410 Special Washers | 410 SS Belleville Washers | Steel 410 Bonded Sealing Washers | 410 Steel Countersunk Finishing Washers |
| SS 410 Dock Washers | 410 SS Fender Washers | Steel 410 Lock Washers | 410 Steel Neoprene Washers |
| SS 410 Square Bevel Washers | 410 SS Star Washers | Steel 410 Spring Washers | 410 Steel Plain Washers |
| SS 410 Metal Washers | 410 SS Wave Washers | Steel 410 Crank Washers | 410 Steel Square Washers |
| SS 410 Hex Washers | 410 SS Star Lock Washers | Steel 410 Aluminium Washers | 410 Steel Thrust Washers |
| SS 410 Serrated Washers | 410 SS Cup Washers | ||
Stainless Steel 410 Washers Available Standards |
|||
| ASTM | ASTM F436 Stainless Steel 410 Washers | ASTM F436M Stainless Steel 410 Washers | ASTM 1985 Stainless Steel 410 Washers |
| DIN | DIN 125 A (ISO 7089) Washers | DIN 125 B (ISO 7090) Washers | DIN 126 Washers |
| DIN 9021 Washers | DIN 440 R Washers | DIN 7349 Washers | |
| DIN 433 Washers | DIN 127 Washers | DIN 128 Washers | |
| DIN 434 Washers | DIN 435 Washers | DIN 1440 Washers | |
| DIN 440v Washers | DIN 6903 Washers | DIN 6916 Washers | |
| DIN 7349 Washers | DIN 7989 Washers | ||
| BS | BS 4320 Form A Washers | BS 4320 Form B Washers | BS 4320 Form C Washers |
| BS 4320 Form D Washers | BS 4395 Washers | ||
| IS / AS | IS 2016 Washers | AS NZS 1252 Washers | |
| JIS | JIS B 1186 Washers | JIS B 1256 Washers | |
| NF | NF E25-513 Z,M Washers | NF E25-513 L,LL Washers | |
